Home / Easun 6.2KW Off Grid Inverter 120A MPPT Charger With WiFi NO parallel

Easun 6.2KW Off Grid Inverter 120A MPPT Charger With WiFi NO parallel

【6.2KW Off Grid Inverter 【120A MPPT+WiFi】

$330.00 USD

Free worldwide shipping

Free returns

Carbon neutral

Secure payments

Ship From

EU

Size

6.2kw

Quantity

Inventory quantity : 94

Description

ISolar-SMG-II-6.2KP-WIFI Manual

Note: ISolar-SMG-II-6.2KW-Wifi.This model cannot be used in parallel. If you need to use units in parallel, please purchase the appropriate model ISolar-SMG-II-6.2KP-Wifi.

Features:

*pure sine wave soalr inverter

*Output power factor 1

*High PV input voltage range

*Built-in MPPT soalr controller

*Battery equalization function to optimize

*Battery performance and extend lifecycle

*Inverter running without barrery

*Built-in anti-dusk kit for harsh environment

*WIFI-GPRS remote monitoring (WIFI Plug included)

*Detachable LCD(Optional)

MODEL	ISolar-SMG-II-6.2KW-Wifi
Capacity	6.2KVA/6.2KW
Parallel Capability	NO
INPUT
Nominal Voltage	230VAC
Acceptable Voltage Range	170-280VAC(For personal Computer);:90-280vac(For Home Appliances)
Frequency	50/60 Hz(Auto sensing)
OUTPUT
Nominal Voltage	220/230VAC+5%
Surge Power	12400VA
Frequency	50/60Hz
Waveform	Pure Sine wave
Peak Eficiency(PV to INV)	96%
Peak Efficiency(Battery to INV)	93%
Crest Factor	3:1
BATTERY
Battery Voltage	48VDC
Floatig Charge Volage	54VDC
OverCharge Protectin	63VDC
Charging Method	CC/ CV
Solar Charger & AC Charger
Max.PV Array Power	6500W
Max.PV Array Open Circuit Voltage	500VDC
PV Array MPPT Voltage Range	60VDC~450VDC
Max.Solar Input Current	27A
Max.Solar Charge Current	120A
Max.AC Charge Current	80A
Max.Charge Current	120A
PHYSICAL
Dimensions,D x W x H(mm)	450300130
Package Dimensions,D x W x H(mm)	540x390x210
Net Weight(Kg)	12
Communication Interface	RS232 / RS485 / Dry-contact
ENVIRONMENT
Operating Temperature Range	(-10°C to 50°C)
Storage Temperature	(-15°C ~ 50°C)
Humidity	5% to 95% Relative Humidity ( Non-condensing )
